A well-known and proven suspension system
The panels can be dismantled and reinstalled without the use of screws, making it easy to access the space above the ceiling for service, maintenance and alterations.
The proven T24 profile system is easy to install and familiar to installers, contributing to an efficient construction process.
By combining the familiar T24 profile system with the Troldtekt tiles T24 design solution, you can create a distinctive ceiling design with a high level of acoustic comfort.
3000
30 pcs.
According to measurements
600
60 pcs.
600x600 mm: 2.8 pcs.
3700
20 pcs.
1.7 pcs.
3000
25 pcs.
According to measurements
175-275
200-360
320-600
540-1000
1035-2000
100 pcs.
1.4 pcs.
K0-S
K0-FS
K5-FS
K0-SB
The natural colour (RAL 1015) has been developed to complement Troldtekt ceiling panels in natural wood, making it possible to create a more cohesive ceiling design, in which the profiles and panels are perceived more as an integrated solution.
The new colour is particularly suited to architecture, where wood and other warm materials set the tone. The T24 profile system is also available in white, black or galvanised steel, allowing you to choose the profile colour that best complements the look of the ceiling.
The T24 profile system consists of a range of components that together form a stable and removable ceiling structure in which the Troldtekt panels are installed without the use of tools.
The range comprises main tees, cross tees, perimeter angle profiles, shadow-edge profiles as well as adjustable quick-hangers. The visible profile width is 24 mm.
The profile system’s modules are 600x600 and 1200x600 and are suitable for Troldtekt panels in 25 and 35 mm thicknesses.
These products can be installed in a T24 profile system:
Castellum in Uppsala chose Troldtekt T24 tiles to create a ceiling that combines the familiar T24 solution with a more distinctive architectural expression. The result is a ceiling that both complements the design of the space and contributes to good acoustics.
See more examples of buildings where Troldtekt panels have been installed with the T24 profile system.
Whether you're working on a large-scale building project or a smaller one, our experts are ready to provide advice and specifications.
Explore other acoustic solutions from Troldtekt.
